Un relay es un dispositivo electrónico que permite controlar un circuito eléctrico mediante una señal de control (se aplica tensión en la bobina). Puede ser utilizado para conectar o desconectar un circuito, o para invertir la polaridad de un circuito.
Tenemos modelos para soldar en placa, con terminales, o para colocar en zócalo:
Zócalos para relays: click aquí
| CODIGO GM | MODELO | Tensión | VDC / VAC | RESISTENCIA DE BOBINA (ohms) | Tipo | Corriente de contactos (A) | Notas | Dim. (mm) | Fig. | |
|---|---|---|---|---|---|---|---|---|---|---|
| CODIGO GM | MODELO | MARCA | Tensión | VDC / VAC | RESISTENCIA DE BOBINA (ohms) | Tipo | Corriente de contactos (A) | Notas | Dim. (mm) | Fig. |
| 81T5 | MZ-5D-K-U | TAKAMIZAWA | 5 | VDC | 60 | 1 INV | 1 | MINI DIP | 15x11x11 | A1 |
| 81T24 | MZF-24HG-C | TAKAMIZAWA | 24 | VDC | 1280 | 1 INV | 1 | MINI DIP | 15x11x11 | A1 |
| 81T24 | MCS1KH-S-24 | MCS | 24 | VDC | 1280 | 1 INV | 1 | MINI DIP | 15x11x11 | A1 |
| FBR211-24 | FBR211NED024M | FUJITSU | 24 | VDC | 2800 | 1 INV | 2 | PARA IMPRESO | 16x11x11 | A2 |
| DS1E-M-5 | DS1E-M-DC5V (polarizado) | AROMAT | 5 | VDC | 60 | 1 INV | 2 | PARA IMPRESO | 15x10x10 | A3 |
| DS1E-S-5 | G6E-134P-ST-US-DC5 | AROMAT | 5 | VDC | 125 | 1 INV | 2 | SENSITIVO P/IMPR. | 15x10x10 | A3 |
| DS1E-M-12 | DS1E-M-DC12V (polarizado) | AROMAT | 12 | VDC | 365 | 1 INV | 2 | PARA IMPRESO | 15x10x10 | A3 |
| DS1E-S-12 | DS1E-S-DC12V (polarizado) | AROMAT | 12 | VDC | 750 | 1 INV | 2 | SENSITIVO P/IMPR. | 15x10x10 | A3 |
| DS1E-M-24 | DS1E-M-DC24V (polarizado) | AROMAT | 24 | VDC | 1440 | 1 INV | 2 | PARA IMPRESO | 15x10x10 | A3 |
| DS1E-S-24 | DS1E-S-DC24V (polarizado) | AROMAT | 24 | VDC | 2880 | 1 INV | 2 | SENSITIVO P/IMPR. | 15x10x10 | A3 |
| BS102-5 | BS-102-5VDC | BESTAR | 5 | VDC | 70 | 1 INV | 3 | MINI DIP | 15x11x11 | A4 |
| BS102-6 | FBR211AD006M | FUJITSU | 6 | VDC | 85 | 1 INV | 3 | MINI DIP | 15x11x11 | A4 |
| BS102-12 | FBR211AD012M | FUJITSU | 12 | VDC | 400 | 1 INV | 3 | MINI DIP | 15x11x11 | A4 |
| TR5VL-12 | TR5VL-12VDC-SZ | TIANBO | 12 | VDC | 720 | 1 INV | 2 | MINI DIP | 12x7x10 | A4 |
| BS102-24 | BS-102-24VDC | BESTAR | 24 | VDC | 1600 | 1 INV | 3 | MINI DIP | 15x11x11 | A4 |
| JQ1P-12V | ALQ112 | AROMAT | 12 | VDC | 360 | 1 INV | 10 | PARA IMPRESO | 20x10x15 | A5 |
| JQ1P-24V | AJQ6342 | AROMAT | 24 | VDC | 1440 | 1 INV | 10 | PARA IMPRESO | 20x10x15 | A5 |
| JQ1P-24V | ALQ124 | PANASONIC | 24 | VDC | 1440 | 1 INV | 10 | PARA IMPRESO | 20x10x15 | A5 |
| 82T5 | T82N11D113-05 | P & B | 5 | VDC | 50 | 2 INV | 2 | DUAL IN LINE | 20x10x10 | B1 |
| DS2E-M-5 | AZ822-2C-5 | OMRON | 5 | VDC | 625 | 2 INV | 2 | PARA IMPRESO | 20x10x10 | B1 |
| DS2E-S-5 | DS2YE-S-DC5V (polarizado) | AROMAT | 5 | VDC | 125 | 2 INV | 2 | SENSITIVO P/IMPR. | 20x10x10 | B1 |
| AZ826-2C-12DME | AZ826-2C-12DME | ZETTLER | 12 | VDC | 400 | 2 INV | 1 | DUAL IN LINE | 20x10x12 | B1 |
| 82T12 | T82BN11D113-12 | P & B | 12 | VDC | 290 | 2 INV | 2 | DUAL IN LINE | 20x10x10 | B1 |
| DS2E-M-12 | G5V-2-DC12 | OMRON | 12 | VDC | 288 | 2 INV | 2 | PARA IMPRESO | 20x10x10 | B1 |
| DS2E-S-12 | DS2YE-S-DC12V (polarizado) | AROMAT | 12 | VDC | 700 | 2 INV | 2 | SENSITIVO P/IMPR. | 20x10x10 | B1 |
| DS2E-S-12 | AZ830-2C-12DSE | ZETTLER | 12 | VDC | 720 | 2 INV | 2 | SENSITIVO P/IMPR. | 20x10x10 | B1 |
| DS2E-S-12 | AZ822-2C-12DSE | ZETTLER | 12 | VDC | 960 | 2 INV | 2 | SENSITIVO P/IMPR. | 20x10x10 | B1 |
| DS2E-M-24 | RY-24W-KR10 | TAKAMIZAWA | 24 | VDC | 1400 | 2 INV | 2 | PARA IMPRESO | 20x10x10 | B1 |
| DS2E-M-24 | G5V-2-DC24 | OMRON | 24 | VDC | 1152 | 2 INV | 2 | PARA IMPRESO | 20x10x10 | B1 |
| DS2E-M-48 | DS2E-M-48 (polarizado) | AROMAT | 48 | VDC | 5760 | 2 INV | 2 | PARA IMPRESO | 20x10x10 | B1 |
| HJR1-2CL-24V | HJR1-2CL-24VDC | TIANBO | 24 | VDC | 2880 | 2 INV | 2 | PARA IMPRESO | 20x10x12 | B1 |
| DS2E-S-24 | AZ822-2C-24DSE | ZETTLER | 24 | VDC | 2880 | 2 INV | 2 | AZ822-2C-24DSE: Sensitivo No Polarizado | 20x10x12 | B1 |
| DS2E-S-24 | FBR244ND024 | FUJITSU | 24 | VDC | 2880 | 2 INV | 2 | FBR244ND024: Sensitivo No Polarizado | 20x10x10 | B1 |
| DS2E-S-24 | RY24W-KR10 | TAKAMIZAWA | 24 | VDC | 2880 | 2 INV | 2 | RY24W-KR10: Sensitivo No polarizado | 20x10x12 | B1 |
| TRK2233-48V | TRK2233-48V | ISKRA | 48 | VDC | 4000 | 2 INV | 2 | DUAL IN LINE | 20x10x10 | B1 |
| DS2E-M-48 | DS2E-M-DC48V (polarizado) | NAIS AROMAT | 48 | VDC | 7680 | 2 INV | 2 | PARA IMPRESO | 20x10x10 | B1 |
| DS2E-S-48 | DS2E-S-DC48V (polarizado) | AROMAT | 48 | VDC | 11520 | 2 INV | 2 | SENSITIVO P/IMPR | 20x10x10 | B1 |
| DS2E-S-48 | FBR244ND048/02CS | FUJITSU | 48 | VDC | 4000 | 2 INV | 2 | SENSITIVO P/IMPR | 20x10x10 | B1 |
| DS2E-SL2-5 | G6AK-274P-ST-US | OMRON | 5 | VDC | 139 | 2 INV | 2 | LATCH P/IMPRESO | 20x10x10 | B2 |
| DS2E-ML2-24 | DS2E-ML2-DC24V (polarizado) | AROMAT | 24 | VDC | 1600 | 2 INV | 2 | LATCH P/IMPRESO | 20x10x10 | B2 |
| DS2E-SL2-24 | DS2E-SL2-DC24V (polarizado) | AROMAT | 24 | VDC | 2880 | 2 INV | 2 | LATCH P/IMPRESO | 20x10x10 | B2 |
| UC2-5NU | UC2-5NU | NEC | 5 | VDC | 178 | 2 INV | 1 | MINI DIP POLARIZADO | 11x6.5x5.3 | B3 |
| FBR12ND-12 | G6N-2Y-DC12V BA-12WD-K | OMRON FUJITSU | 12 | VDC | 970 | 2 INV | 2 | MINI DIP | 14x7x10 | B3 |
| FBR12ND-24 | FBR12ND-24 | FUJITSU | 24 | VDC | 2800 | 2 INV | 2 | MINI DIP | 14x7x10 | B3 |
| TQ2-5V | TQ2-5V A-5WN-K | AROMAT TAKAMIZAWA | 5 | VDC | 178 | 2 INV | 1 | MINI DIP | 14x9x5 | B4 |
| TQ2-12V | TQ2E-12V A-12W-K | AROMAT TAKAMIZAWA | 12 | VDC | 1028 | 2 INV | 1 | MINI DIP | 14x9x5 | B4 |
| TQ2-24V | G6H-2-100-24VDC | OMRON | 24 | VDC | 2880 | 2 INV | 1 | MINI DIP | 14x9x5 | B4 |
| FBR46ND-5 | FBR46ND005-P-15 | FUJITSU | 5 | VDC | 125 | 2 INV | 1 | DUAL IN LINE | 16x10x8 | B5 |
| FBR46ND-12 | FBR46ND012-P | FUJITSU | 12 | VDC | 720 | 2 INV | 1 | DUAL IN LINE | 16x10x8 | B5 |
| FBR46ND-24 | FBR46ND024-P-15 | FUJITSU | 24 | VDC | 2304 | 2 INV | 1 | DUAL IN LINE | 16x10x8 | B5 |
| DS4E-M-5 | DS4E-M-DC5V (polarizado) | AROMAT | 5 | VDC | 63 | 4 INV | 2 | PARA IMPRESO | 35x10x10 | C |
| DS4E-S-5 | DS4E-S-DC5V (polarizado) | AROMAT | 5 | VDC | 125 | 4 INV | 2 | SENSITIVO PARA IMPRESO | 35x10x10 | C |
| DS4E-SL2-5 | DS4E-SL2-DC5V (polarizado) | AROMAT | 5 | VDC | 139 | 4 INV | 2 | LATCH P/IMPRESO | 35x10x10 | C |
| DS4E-S-12 | DS4E-S-DC12V (polarizado) | AROMAT | 12 | VDC | 720 | 4 INV | 2 | SENSITIVO PARA IMPRESO | 35x10x10 | C |
| DS4E-S-24 | RA4-24WM-K | TAKAMIZAWA | 24 | VDC | 2880 | 4 INV | 2 | SENSITIVO P/IMPR. | 35x10x10 | C |
| DS4E-M-48 | DS4E-M-DC48V (polarizado) | AROMAT | 48 | VDC | 5760 | 4 INV | 2 | PARA IMPRESO | 35x10x10 | C |
| S2EB-12V | S2EB-12V (polarizado) | OMRON | 12 | VDC | 720 | 2NO / 2NC | 4 | SENSITIVO | 29x12x10 | D |
| G4A-1A-PE-5V | G4A-1A-PE-5VDC | OMRON | 5 | VDC | 27 | 1 NO | 20 | PARA IMPRESO | 30x16x23 | E1 |
| G4A-1A-E-12V | G4A-1A-E-12VDC | OMRON | 12 | VDC | 160 | 1 NO | 20 | TERMINALES PALA | 30x16x23 | E2 |
| TRAF-12-SH | HF102F-12VDC | HONGFA | 12 | VDC | 160 | 1 NO | 20 | TERMINALES PALA | 30x16x23 | E2 |
| JM1AN-TMP-12V | JM1AN-TMP-DC12V | AROMAT | 12 | VDC | 160 | 1 NO | 20 | TERMINALES PALA | 30x16x26 | E2 |
| TRAF-24-SH | TRAF-24VDC-SH | TIANBO | 24 | VDC | 640 | 1 NO | 20 | TERMINALES PALA | 30x16x23 | E2 |
| JR1AF-TMP-12V | JR1AF-TMP-DC12V | AROMAT | 12 | VDC | 270 | 1 NO | 16 | TERMINALES PALA | 28X13X28 | E3 |
| G2R-1-6 | HR-CR311DC006 | HAN KUK | 6 | VDC | 68 | 1 INV | 5 | PARA IMPRESO | 28x12x20 | F1 |
| G2R-1-12 | VB-12TCU-E | FUJITSU | 12 | VDC | 200 | 1 INV | 5 | PARA IMPRESO | 28x12x20 | F1 |
| G2R-1-24 | VB-24TCU-E | FUJITSU | 24 | VDC | 820 | 1 INV | 5 | PARA IMPRESO | 28x12x20 | F1 |
| G2R-1-24 | JW1FSN-DC24V | AROMAT | 24 | VDC | 1100 | 1 INV | 10 | PARA IMPRESO | 28x12x20 | F1 |
| G2R-1-48 | VS-48STBU-5 | TAKAMIZAWA | 48 | VDC | 4400 | 1 INV | 10 | PARA IMPRESO | 29x13x25 | F1 |
| RY210012 | RY210012 | TE CONNECTIVITY | 12 | VDC | 1200 | 1 INV | 8 | PARA IMPRESO | 28x10x12 | F2B |
| RY210024 | RY210024 | TE CONNECTIVITY | 24 | VDC | 2350 | 1 INV | 8 | PARA IMPRESO | 28x10x12 | F2B |
| G6RN-24V | V23061-B1007-A401 | SCHRACK | 24 | VDC | 2270 | 1 INV | 8 | PARA IMPRESO | 30x10x15 | F2B |
| AZ755-1C-12 | AZ755-1C-12D | ZETTLER | 12 | VDC | 275 | 1 INV | 16 | DOBLE CONTACTO | 28x12x25 | F3 |
| AZ755-1C-12 | FBR611NDO12-K | FUJITSU | 12 | VDC | 275 | 1 INV | 16 | DOBLE CONTACTO | 28x12x25 | F3 |
| AZ755-1C-12 | G2R-1E-12 | OMRON | 12 | VDC | 275 | 1 INV | 16 | DOBLE CONTACTO | 28x12x25 | F3 |
| AZ755-1C-24 | 793-P-1C-B-24VDC | SONG CHUAN | 24 | VDC | 1100 | 1 INV | 16 | DOBLE CONTACTO | 28x12x25 | F3 |
| G2R-1A-AC230 | G2R-1A-T130-230VAC | OMRON | 220 | VAC | 30000 | 1 NO | 10 | PARA IMPRESO | 28x12x25 | G0 |
| RKA-7DZ-5 | G2R-2A-DC5 | OMRON | 5 | VDC | 47 | 2 NO | 5 | - | 28x12x25 | G1 |
| RKA-7DZ-12 | G2R-2A-DC12 | P & B | 12 | VDC | 270 | 2 NO | 5 | - | 28x12x25 | G1 |
| TRA5D-12V | TRA5D-12VDC | TIANBO | 12 | VDC | 576 | 2 NO | 5 | - | 24x13x25 | G1 |
| RKA-7DZ-24 | G2R-2A-DC24 | P & B | 24 | VDC | 1100 | 2 NO | 5 | - | 28x12x25 | G1 |
| TRA5D-24V | TRA5D-24VDC | TIANBO | 24 | VDC | 2304 | 2 NO | 5 | - | 24x13x25 | G1 |
| G2R-2-12 | JW2SN-DC12V | NAIS | 12 | VDC | 270 | 2 INV | 5 | DIP PARA IMPRESO | 28x12x25 | G2 |
| G2R-2-24 | JW2SN-DC24V | NAIS | 24 | VDC | 1100 | 2 INV | 5 | DIP PARA IMPRESO | 28x12x25 | G2 |
| G2R-2-48 | FBR621ND048 | FUJITSU | 48 | VDC | 4400 | 2 INV | 6 | DIP - SENSITIVO | 29x13x25 | G2 |
| G2R-1A-E5 | G2R-1A-E5VDC | OMRON | 5 | VDC | 47 | 1 NO | 16 | DOBLE CONTACTO | 29x13x25 | G3 |
| RT334024 | H-550-1537 | HENGSTLER | 24 | VDC | 1100 | 1 NO | 16 | DOBLE CONTACTO | 29x12x26 | G3 |
| JS1A-12V | JS1A-12V | NAIS | 12 | VDC | 400 | 1 NO | 10 | PARA IMPRESO | 27x21x21 | H0 |
| JS1A-24V | JS1A-24V | NAIS | 24 | VDC | 1600 | 1 NO | 10 | PARA IMPRESO | 22x16x16 | H0 |
| HG4230-5 | HG4230-005-Z1C | HIGHGUARD | 5 | VDC | 80 | 1 INV | 6 | PARA IMPRESO | 19x16x16 | H1 |
| HG4130-5 | JQL-3F(T73)-5 | QIANJI | 5 | VDC | 100 | 1 INV | 10 | PARA IMPRESO | 19x16x16 | H1 |
| HG4130-9 | JS1-9V | NAIS | 9 | VDC | 225 | 1 INV | 10 | PARA IMPRESO | 19x16x16 | H1 |
| HG4130-12 | JS1-12V | NAIS | 12 | VDC | 225 | 1 INV | 10 | PARA IMPRESO | 19x16x16 | H1 |
| HG4130-12 | G5LE-14 | OMRON | 12 | VDC | 370 | 1 INV | 10 | PARA IMPRESO | 19x16x16 | H1 |
| HG4130-12 | AZ943-1CH-12DE | ZETTLER | 12 | VDC | 400 | 1 INV | 15 | PARA IMPRESO | 19x16x16 | H1 |
| AZ9321-1C-12DEF | AZ9321-1C-12DEF | ZETTLER | 12 | VDC | 400 | 1 INV | 20 | PARA IMPRESO | 22x16x16 | H1 |
| HG4130-24 | FBR111VD024-W | FUJITSU | 24 | VDC | 1200 | 1 INV | 10 | PARA IMPRESO | 19x16x16 | H1 |
| FBR166NDC024-WB | FBR166NCD024-WB | FUJITSU | 24 | VDC | 420 | 1 INV | 25 | PARA IMPRESO | 22x16x16 | H1 |
| HG4130-48 | JS1-48V-F | FUJITSU | 48 | VDC | 6400 | 1 INV | 10 | PARA IMPRESO | 22x16x16 | H1 |
| A410-6VDC | A410-367410-11 | GUARDIAN | 6 | VDC | 74 | 1 NO | 10 | - | 21x17x16 | H2 |
| A410-9VDC | A410-367411-18 | GUARDIAN | 9 | VDC | 174 | 1 NO | 10 | - | 21x17x16 | H2 |
| A410-12VDC | LZ-12VM-C | TAKAMISAWA | 12 | VDC | 310 | 1 NO | 10 | - | 21x17x16 | H2 |
| A410I-5VDC | AZ810-1CH-5DSE | ZETTLER | 5 | VDC | 80 | 1 INV | 6 | - | 21x17x16 | H3 |
| A410I-12VDC | AZ8-1CH-12DSE | ZETTLER | 12 | VDC | 440 | 1 INV | 3 | - | 21x17x16 | H3 |
| A410I-12VDC | LZ-12H-C-UC | TAKAMISAWA | 12 | VDC | 440 | 1 INV | 3 | - | 21x17x16 | H3 |
| A410I-24VDC | AZ8-1C-24DE | ZETTLER | 24 | VDC | 1320 | 1 INV | 3 | - | 21x17x16 | H3 |
| A410I-24VDC | LZ-24H-KUC | TAKAMISAWA | 24 | VDC | 1320 | 1 INV | 3 | - | 21x17x16 | H3 |
| AZ7-2-6 | AZ7-2D-6DE | ZETTLER | 6 | VDC | 140 | 2 INV | 2 | P/IMPRESO (CHATO) | 31x25x16 | I1 |
| AZ7-2-12 | FBR464D012/02CT | FUJITSU | 12 | VDC | 500 | 2 INV | 2 | P/IMPRESO (CHATO) | 30x20x10 | I1 |
| AZ7-2-12 | NF2E-12V | NAIS | 12 | VDC | 500 | 2 INV | 2 | P/IMPRESO (CHATO) | 30x20x10 | I1 |
| AZ7-2-24 | FBR464D024/02CT | FUJITSU | 24 | VDC | 2100 | 2 INV | 2 | P/IMPRESO (CHATO) | 30x20x10 | I1 |
| AZ7-2-24 | NF2-24V1-H50 | NAIS | 24 | VDC | 2100 | 2 INV | 2 | P/IMPRESO (CHATO) | 30x20x10 | I1 |
| AZ7-4-5 | AZ7P-E-4C-5D | ZETTLER | 5 | VDC | 55 | 4 INV | 2 | P/IMPRESO (CHATO) | 30x25x11 | I2 |
| AZ7-4-5 | NF4EB-5V | NAIS | 5 | VDC | 55 | 4 INV | 2 | P/IMPRESO (CHATO) | 30x25x11 | I2 |
| AZ7-4-12 | AZ7-4C-12D | ZETTLER | 12 | VDC | 330 | 4 INV | 2 | P/IMPRESO (CHATO) | 30x25x11 | I2 |
| AZ7-4-24 | FBR464ND024/04C | FUJITSU | 24 | VDC | 1200 | 4 INV | 2 | P/IMPRESO (CHATO) | 30x25x11 | I2 |
| AZ7-4-48 | AZ7-4C-48V | ZETTLER | 48 | VDC | 3940 | 4 INV | 2 | P/IMPRESO (CHATO) | 30x25x11 | I2 |
| HA1-DC12V | HA1-DC12V | AROMAT | 12 | VDC | 400 | 1 INV | 3 | PARA IMPRESO | 36x24x27 | J |
| HA1-DC24V | HA1-DC24V | AROMAT | 24 | VDC | 1600 | 1 INV | 3 | PARA IMPRESO | 36x24x27 | J |
| W90S5D12 | JQX-15F-1Z-12VDC | ASIAON | 12 | VDC | 160 | 1 INV | 20 | POTENCIA | 32x28x21 | K1 |
| W90S5D24 | CDE813-24DO | CDE | 24 | VDC | 650 | 1 INV | 20 | POTENCIA | 32x28x21 | K1 |
| 490-21C2F0 | 490-21C2F0 | MIDTEX | 24 | VDC | 660 | 1 INV | 20 | POTENCIA | 32x28x21 | K1 |
| AZ2150-1C-12 | AZ2150-1C-12DEF | ZETTLER | 12 | VDC | 155 | 1 INV | 30 | POTENCIA | 32x28x21 | K1 |
| AZ2150-1C-24 | AZ2150-1C-24DEF | ZETTLER | 24 | VDC | 660 | 1 INV | 30 | POTENCIA | 32x28x21 | K1 |
| AZ2150-1C-24 | JT1E-B-DC24V | NAIS AROMAT | 24 | VDC | 660 | 1 INV | 30 | POTENCIA | 32x28x21 | K1 |
| 2266 | R10S-E1-Y2-J1.0K | P & B | 5 | VDC | 1000 | 2 INV | 3 | SENSITIVO (4.5mA) | 24x18x30 | L2 |
| AZ420-2-6 | Y2B8A1-C-C | ZETTLER | 6 | VDC | 52 | 2 INV | 2 | - | 24x18x30 | L2 |
| AZ420-2-12 | AZ420-1011-40LUS | ZETTLER | 12 | VDC | 180 | 2 INV | 2 | - | 24x18x30 | L2 |
| 3440 | R10-E1-Y2-J1.0K | P & B | 12 | VDC | 1000 | 2 INV | 2 | SENSITIVO (8.5mA) | 24x18x30 | L2 |
| 3579 | R10-E1-Y2-V700 | P & B | 24 | VDC | 700 | 2 INV | 2 | ZOCALO:1031 | 24x18x30 | L2 |
| 3579 | TP154-CC-24 | ALLIED CONTROL | 24 | VDC | 700 | 2 INV | 2 | ZOCALO:1031 | 24x18x30 | L2 |
| 2084 | R10-E1-Y2-V2.5K | P & B | 48 | VDC | 2500 | 2 INV | 2 | ZOCALO:1031 | 29x23x35 | L2 |
| PR16C09-6V | PR16C09-6V | ISKRA | 6 | VDC | 110 | 2 INV | 5 | - | 30x18x30 | L3 |
| 721 | RLQD-240A-Q | SSAC | 220 | VAC | 19800 | 2 INV | 10 | - | 25x20x35 | L3 |
| AZ421-4-6 | T154X1-266 | GOULD | 6 | VDC | 50 | 4 INV | 2 | ZOCALO:1032 | 30x18x30 | L4 |
| 2004 | R10-E1-Y4-V185 | P & B | 12 | VDC | 185 | 4 INV | 2 | ZOCALO:1032 | 30x18x30 | L4 |
| AZ421-4-12 | AZ421-1011-1L | ZETTLER | 12 | VDC | 182 | 4 INV | 2 | ZOCALO:1032 | 30x18x30 | L4 |
| AZ421-4-24 | 70R4T-24 | SIGMA | 24 | VDC | 700 | 4 INV | 2 | ZOCALO:1032 | 30x18x30 | L4 |
| AZ421-4-24 | 70R4S25 | SIGMA | 24 | VDC | 700 | 4 INV | 2 | ZOCALO:1032 | 30x18x30 | L4 |
| 2188 | R10-E1-M4-V700 | P & B | 24 | VDC | 700 | 4 INV | 5 | ZOCALO:1032 | 30x18x30 | L4 |
| 2270 | R10-E2-Y4-J2.5K | P & B | 24 | VDC | 2500 | 4 INV | 3 | SENSITIVO (8.4mA) | 30x18x30 | L4 |
| 888 | KHU17D11-6 | P & B | 6 | VDC | 40 | 4 INV | 3 | - | 27x21x34 | L5 |
| 886 | FRL263A240/04CS | FUJITSU | 220 | VAC | 13000 | 4 INV | 5 | CON BASE | 27x21X34 | L5 |
| 5905-1C-24V | ZD111024 | SCHRACK | 24 | VDC | 650 | 1 INV | 20 | SIN CARCAZA | 28x22x16 | LL1 |
| 3197 | JRE2DB1-5 | P & B | 5 | VDC | 200 | 1 NC | 1 | DRY REED RELAY | 24x10x9 | M1 |
| 3198 | JRE2DB1-12 | P & B | 12 | VDC | 900 | 1 NC | 1 | DRY REED RELAY | 24x10x9 | M1 |
| 3207 | JRE50DC1-5 | P & B | 5 | VDC | 50 | 1 NO / 1 NC | 1 | DRY REED RELAY | 24x14x9 | M2 |
| 3204 | JRE7DB1-5 | P & B | 5 | VDC | 120 | 2 NO | 1 | DRY REED RELAY | 24x10x9 | M3 |
| 2077 | R50-E2-Y1-5V | P & B | 5 | VDC | 43 | 1 INV | 2 | PARA IMPRESO | 27x15x11 | N1 |
| 2190 | R50-E2-Y1-12V | P & B | 12 | VDC | 200 | 1 INV | 2 | PARA IMPRESO | 27x15x11 | N1 |
| 2191 | R50-E2-Y1-24V | P & B | 24 | VDC | 950 | 1 INV | 2 | PARA IMPRESO | 27x15x11 | N1 |
| 2192 | R50-E2-Y2-5V | P & B | 5 | VDC | 32 | 2 INV | 2 | PARA IMPRESO | 27x22x11 | N2 |
| 703 | KUP5A51-120VAC | P & B | 110 | VAC | 2300 | 1 INV | 5 | - | 38x40x58 | O1 |
| 710 | KUP5D51-24VDC | P & B | 24 | VDC | 470 | 1 INV | 5 | - | 38x40x58 | O1 |
| 700 | KUP1A51-120VAC | P & B | 110 | VAC | 2300 | 1 NO | 5 | - | 38x40x58 | O2 |
| HP32-M-DC12V | KUP11D15-12 | AROMAT | 12 | VDC | 120 | 2 INV | 10 | - | 35x35x45 | O3 |
| RMQ-24D-2A | KUP11D15-24 | SSAC | 24 | VDC | 470 | 2 INV | 10 | - | 35x35x45 | O3 |
| RMQ-120A-2A | KUP11A15-120 | SSAC | 110 | VAC | 2250 | 2 INV | 10 | - | 35x35x45 | O3 |
| RMQ-240A-2A | KUP11A15-240 | SSAC | 220 | VAC | 9110 | 2 INV | 10 | - | 35x35x45 | O3 |
| 750 | KRUP240 | KEST | 220 | VAC | 7000 | 3 INV | 10 | - | 38x34x51 | O4 |
| 725 | KRP3DH-12V | P & B | 12 | VDC | 120 | 1 NO | 20 | - | 34x34x71 | P1 |
| 245 | KRP5DY-24VDC | P & B | 24 | VDC | 470 | 1 INV | 5 | - | 34x34x64 | P2 |
| 279 | KRP11A-24V | P & B FUJITSU | 24 | VAC | 85 | 2 INV | 10 | - | 34x34x51 | P3 |
| 279 | FRL256A024/02CS | P & B FUJITSU | 24 | VAC | 85 | 2 INV | 10 | - | 34x34x51 | P3 |
| 280 | PR58B | ISKRA | 110 | VAC | 2000 | 2 INV | 10 | - | 34x34x51 | P3 |
| 280 | KRP11AG-115V | ISKRA | 110 | VAC | 2000 | 2 INV | 10 | - | 34x34x51 | P3 |
| 281 | KRP11A-240V | P & B | 220 | VAC | 8500 | 2 INV | 10 | - | 34x34x51 | P3 |
| 281 | RMP-240A-2 | SSAC | 220 | VAC | 8500 | 2 INV | 10 | - | 34x34x51 | P3 |
| MK2KP-DC48 | MK2KP-UA | OMRON | 48 | VDC | 1630 | 2 INV | 10 | CON LATCH | 34x34x51 | P4 |
| 307 | MKH3A-120VAC | LINE | 110 | VAC | 1800 | 3 INV | 10 | - | 34x34x51 | P5 |
| 307 | KRP14A-115VAC | LINE | 110 | VAC | 1800 | 3 INV | 10 | - | 34x34x51 | P5 |
| 308 | RMP240A3 | SSAC | 220 | VAC | 9200 | 3 INV | 10 | - | 34x34x65 | P5 |
| 324 | RMP12D3 | SSAC | 12 | VDC | 120 | 3 INV | 10 | - | 49x49x80 | P5 |
| 306 | KRPA14AY-24 RMP-24A-3 | SSAC / P&B | 24 | VAC | 85 | 3 INV | 5 | - | 35x35x64 | P5 |
| 679 | PM17DY-12V | P & B | 12 | VDC | 33 | 4 INV | 25 | - | 67x86x69 | Q |
| 3157 | PRD5DY0-6V | P & B | 6 | VDC | 18 | 1 INV | 25 | - | 83x83x74 | R1 |
| 3173 | PRD11AY0-6V | P & B | 6 | VAC | 86 | 2 INV | 25 | - | 110x89x86 | R2 |
| 3180 | 425BXX-220AC | STANDARD | 220 | VAC | 1200 | 2 NO | 30 | - | 64x64x58 | R2 |
| 3184 | PRD11DYO-6V | P & B | 6 | VDC | 18 | 2 INV | 25 | - | 90x68x62 | R2 |
| 414 | MR5D-12VDC | P & B | 12 | VDC | 100 | 1 INV | 8 | - | 75x25x45 | R3 |
| 6503 | S87R11A2B1D1-24V | P & B | 24 | VAC | 32 | 2 INV | 20 | USO INDUSTRIAL | 47x30x58 | S |
| 6504 | S87R11A2B1D1-120 | P & B | 110 | VAC | 800 | 2 INV | 20 | USO INDUSTRIAL | 47x30x58 | S |
| 3103 | CGB-38-79050M | P & B | 110 | VAC | 0 | 2 INV | 10 | PULSO 5 a 50 min | 95x80x123 | T2 |
| 1050 | CB-1050B80 | P & B | 220 | VAC | 0 | 2 INV | 10 | RETARDO 0.1 a 10s | 60x43x88 | T2 |
| 3100 | CGD-38-39050M | P & B | 24 | VDC | 0 | 2 INV | 10 | PULSO 5 a 50 min | 90x74x118 | T2 |
| 3106 | CGD-38-30050M | P & B | 24 | VDC | 0 | 2 INV | 10 | RETARDO 5 a 50min | 100x85x136 | T2 |
| AZ2900-1A-24AP | AZ2900-1A-24AP(G) | ZETTLER | 24 | VAC | 77 | 1 NO | 25 | TERMINALES PALA | 30x27x45 | U1 |
| TRV4L-12-T | TRV4L-12V-T | GS | 12 | VDC | 90 | 2 NO | 40 | TERMINALES PALA | 28x28x25 | V |
| G7L-1A-24 | G7L-1A-TUBJ-CB-24 | OMRON | 24 | VDC | 303 | 1 NO | 25 | TERMINALES PALA | 83x48x51 | W |
| G7L-1A-AC220 | G7L-1A-TUBJ-CB-220 | OMRON | 220 | VAC | 21000 | 1 NO | 25 | TERMINALES PALA | 83x48x51 | W |
| G7L-2A-AC220 | G7L-2A-BUBJCB-220 | OMRON | 220 | VAC | 21000 | 2 NO | 25 | CON TORNILLOS | 83x48x64 | W |
| JC1A1B-TM-12 | JC1A1B-TM-DC12V | AROMAT | 12 | VDC | 160 | 1 NO / 1 NC | 15 | TERMINALES PALA | 40x29x42 | X0 |
| JA1A-TMP-AC240 | JA1A-TMP-AC240V-P | AROMAT | 220 | VAC | 14000 | 1 NO | 25 | TERMINALES PALA | 35x30x28 | X2 |
| T91P5A32-240 | T91P5A32-240 | P & B | 220 | VAC | 12000 | 1 INV | 15 | TERMINALES PALA | 30x25x27 | X3 |
| JTN1S-TMP12 | JTN1S-TMP-F-DC12 | AROMAT | 12 | VDC | 180 | 1 INV | 20 | TERMINALES PALA | 32x27x28 | X4 |
| PA1A-12V | APAN3112 | AROMAT | 12 | VDC | 1200 | 1 NO | 5 | SLIM 5mm de ancho | 5x20x13 | Y1 |
| PA1A-24V | APAN3124 | AROMAT | 24 | VDC | 3200 | 1 NO | 5 | SLIM 5mm de ancho | 5x20x13 | Y1 |
| SR-1C-12V | SR-1C-AD12V-E (PSR-1C-12-E) | HONEYWELL | 12 | VDC | 848 | 1 INV | 6 | SLIM 5mm de ancho CON ZOCALO DIN | 5x28x15 | Y2 |
| MY2-12V | GR-2C-DC12V | HONEYWELL | 12 | VDC | 160 | 2 INV | 5 | ZOCALO DIN: SMF-08N ZOCALO: SMB-08 | 28x22x36 | Z1 |
| MY2-24V | SZR-MY2-1-DC24V | HONEYWELL | 24 | VDC | 650 | 2 INV | 5 | ZOCALO DIN: SMF-08N ZOCALO: SMB-08 | 28x22x36 | Z1 |
| MY2-220VAC | SZR-MY2-1-AC220V | HONEYWELL | 220 | VAC | 12950 | 2 INV | 5 | ZOCALO DIN: SMF-08N ZOCALO: SMB-08 | 28x22x36 | Z1 |
| GR-2C-220V | GR-2C-AC230V | HONEYWELL | 220 | VAC | 13000 | 2 INV | 5 | ZOCALO DIN: SMF-08N ZOCALO: SMB-08 | 28x22x36 | Z1 |
| MY4-12V | SZR-MY4-1-DC12V | HONEYWELL | 12 | VDC | 160 | 4 INV | 3 | ZOCALO DIN: SMF-14N ZOCALO: SMB-14 | 28x22x36 | Z2 |
| GR-4C-12V | GR-4C-DC12V | HONEYWELL | 12 | VDC | 160 | 4 INV | 5 | CON LED INDICADOR ZOCALO DIN: PGR-4C-E | 28x22x36 | Z2 |
| MY4-24V | SZR-MY4-1-DC24V | HONEYWELL | 24 | VDC | 650 | 4 INV | 3 | ZOCALO: SMF-14N ZOCALO: SMB-14 | 28x22x36 | Z2 |
| GR-4C-24V | GR-4C-DC24V | HONEYWELL | 24 | VDC | 630 | 4 INV | 5 | CON LED INDICADOR ZOCALO DIN: PGR-4C-E | 28x22x36 | Z2 |
| MY4-110VAC | SZR-MY4-S-N1-AC110/120V | HONEYWELL | 110 | VAC | 3750 | 4 INV | 3 | ZOCALO DIN: SMF-14N ZOCALO: SMB-14 | 28x22x36 | Z2 |
| MY4-220VAC | SZR-MY4-1-AC220V | HONEYWELL | 220 | VAC | 12950 | 4 INV | 3 | ZOCALO DIN: SMF-14N ZOCALO: SMB-14 | 28x22x36 | Z2 |
| GR-4C-110V | GR-4C-AC110V | HONEYWELL | 110 | VAC | 3750 | 4 INV | 5 | CON LED INDICADOR ZOCALO DIN: PGR-4C-E | 28x22x36 | Z2 |
| LY2-24V | SZR-LY2-1-DC24V | HONEYWELL | 24 | VDC | 650 | 2 INV | 10 | ZOCALO DIN: SLF-08S ZOCALO: SLB-08 | 28x22x36 | Z3 |
| LY2-S-24V | LY2-S-24V | HONEYWELL | 24 | VDC | 650 | 2 INV | 10 | CON LED INDICADOR ZOCALO DIN: PGR-4C-E | 28x22x36 | Z3 |
| LY2-UA-DC24 | LY2-UA-DC24 | OMRON | 24 | VDC | 650 | 2 INV | 10 | ZOCALO DIN: SLF-08S ZOCALO: SLB-08 | 28x22x36 | Z3 |
| KRLY2-24V | KRLY2024 | KEST | 24 | VDC | 650 | 2 INV | 10 | ZOCALO DIN: SLF-08S ZOCALO: SLB-08 | 28x22x36 | Z3 |
| KRLY2-48V | KRLY2048 | KEST | 48 | VDC | 2500 | 2 INV | 10 | ZOCALO DIN: SLF-08S ZOCALO: SLB-08 | 28x22x36 | Z3 |
| KRLY2-120VAC | KRLY2120 JQX-13F-2C-120 | KEST | 110 | VAC | 5000 | 2 INV | 10 | ZOCALO DIN: SLF-08S ZOCALO: SLB-08 | 28x22x36 | Z3 |
| LY2-220VAC | LY2-UD-AC220 | OMRON | 220 | VAC | 12950 | 2 INV | 10 | ZOCALO DIN: SLF-08S ZOCALO: SLB-08 | 28x22x36 | Z3 |
| KRLY2-220VAC | KRLY2240 | KEST | 220 | VAC | 18000 | 2 INV | 10 | ZOCALO DIN: SLF-08S ZOCALO: SLB-08 | 28x22x36 | Z3 |
| LY4-S-12V | SZR-LY4-S-N1 DC12V | HONEYWELL | 12 | VDC | 96 | 4 INV | 10 | CON LED INDICADOR | 42x28x36 | Z4 |
| LY4-S-24V | SZR-LY4-S-N1 DC24V | HONEYWELL | 24 | VDC | 360 | 4 INV | 10 | CON LED INDICADOR | 42x28x36 | Z4 |
| LY4-S-220V | SZR-LY4-S-N1 AC220V | HONEYWELL | 220 | VAC | 6700 | 4 INV | 10 | CON LED INDICADOR | 42x28x36 | Z4 |
| G2R-1S-24 | G2R-1-S-DC24(S) | OMRON | 24 | VDC | 1113 | 1 INV | 10 | - | 29x13x36 | Z5 |
| CR-2C-12VDC | CR-2C-DC12V | HONEYWELL | 12 | VDC | 270 | 2 INV | 8 | ZOCALO DIN: PCR-2C-T | 29x13x34 | Z6 |
| G2R-2S-12 | G2R-2-S-DC12(S) | OMRON | 12 | VDC | 278 | 2 INV | 5 | ZOCALO DIN: PCR-2C-T | 29x13x36 | Z6 |
| CR-2C-24VDC | CR-2C-DC24V | HONEYWELL | 24 | VDC | 1090 | 2 INV | 8 | ZOCALO DIN: PCR-2C-T | 29x13x34 | Z6 |
| CR-2C-220V | CR-2C-AC230V | HONEYWELL | 220 | VAC | 48000 | 2 INV | 8 | ZOCALO DIN: PCR-2C-T | 29x13x34 | Z6 |
| RJ1S-CL-DC24 | RJ1S-CL-D24 | IDEC | 24 | VDC | 1080 | 1 INV | 16 | ZOCALO DIN: SJ1S-07L | 29x13x36 | Z7 |
| RJ1S-CL-AC220 | RJ1S-CL-A220 | IDEC | 220 | VAC | 25570 | 1 INV | 16 | ZOCALO DIN: SJ1S-07L | 29x13x36 | Z7 |
| RY2S-U-AC24 | RY2S-U-AC24 | IDEC | 24 | VAC | 300 | 2 INV | 3 | ZOCALO DIN: SY2S-05C | 28x14x35 | Z8 |
| JQX-62F/1Z-12 | JQX-62F/1Z-12 | QIANJI | 12 | VDC | 72 | 1 INV | 100 | - | 65x60x50 | Z9 |
| JQX-62F/1Z-24 | JQX-62F/1Z-24 | QIANJI | 24 | VDC | 288 | 1 INV | 100 | - | 65x60x50 | Z9 |
